Revolution's cash recycler products and solutions are designed with one goal in mind: Automate the Cash Handling Process. By recycling cash and improving store analytics, Revolution helps reduce costs and increase profitability.

QuantumTM Series

Revolution’s Quantum Series was developed to be one of the world’s first under-the-counter cash and coin recyclers. This new best-in-class Cash Automation Technology was designed for small footprint businesses with 1-10 cash registers. This multi-till cash recycler is compact and flexible; it can be utilized under the front counter or in the back office. It is ideal for QSR, C-Store, Casual Dining, or any enterprise with 1-10 registers.

Spend more time focused on customer facing activities and managing your business while the Revolution Quantum Series automates your cash management process.

Quantum – World’s First completely under the counter Cash and Coin Recycler designed for lower cash volume business (C-Store, QSR, Pharmacy, Small Box Retail).

Model Recycling
Coin
Capacity
Recycling
Note
Capacity
#
Recycling
Cassettes
#
Deposit
Cassettes
Quantum TM Series
Quantum 4S 9,950 2,740 4 1
Quantum 4S XL 9,950 4,940 4 2

Quantum 4S

SPECIFICATIONS

Height: 30.8” (781 mm)

Width: 32.0” (813 mm)

Depth: 24.1” (611 mm) install depth
Depth: 24.0” (610 mm) servicing depth
Depth: 27.8” (707 mm) transit/transportation clearance

Weight: 440 lbs. (199.5 kg) empty

HARDWARE FEATURES
  • 10″ Touch Screen Color Display
  • Optional Integrated Biometrics
  • Closed Loop Architecture of Notes and Coins
  • Additional Deposit Capacity in the 4S XL Model
  • Coin Discrimination (i.e. Counterfeit Coin Rejection)
  • Recycle and Lockable Deposit Cassettes
  • “Fitness Sort” on Recycled Notes
  • Flexible Note Orientation (No Need to Separate or Face Notes)
  • Integrated Drop/Storage Vault in the 4S Model
  • Optional Integrated Printer
  • Scalable Platform
  • Network and Cluster Multiple Devices
  • Continuous 24/7 Monitoring
  • Vault – UL 291 Business “Hours Rated”
  • UPS Included

Quantum 4S with Auxiliary Vault

SPECIFICATIONS

Height: 30.8” (781 mm)

Width: 44.0” (1118 mm)

Depth: 24.1” (611 mm) install depth
Depth: 24.0” (610 mm) servicing depth
Depth: 27.8” (707 mm) transit/transportation clearance

Weight: 715 lbs. (324 kg) empty

HARDWARE FEATURES
  • 10″ Touch Screen Color Display
  • Optional Integrated Biometrics
  • Closed Loop Architecture of Notes and Coins
  • Additional Deposit Capacity in the 4S XL Model
  • Coin Discrimination (i.e. Counterfeit Coin Rejection)
  • Recycle and Lockable Deposit Cassettes
  • “Fitness Sort” on Recycled Notes
  • Flexible Note Orientation (No Need to Separate or Face Notes)
  • Integrated Drop/Storage Vault in the 4S Model
  • Optional Integrated Printer
  • Scalable Platform
  • Network and Cluster Multiple Devices
  • Continuous 24/7 Monitoring
  • Vault – UL 291 Business “Hours Rated”
  • UPS Included
  • Auxiliary Vault – 2.64 Cubic Feet Internal Space; Each Unit Comes with 2 Adjustable Shelves

Quantum 4S XL

SPECIFICATIONS

Height: 30.8” (781 mm)

Width: 32.0” (813 mm)

Depth: 24.1” (611 mm) install depth
Depth: 24.0” (610 mm) servicing depth
Depth: 27.8” (707 mm) transit/transportation clearance

Weight: 440 lbs. (199.5 kg) empty

HARDWARE FEATURES
  • 10″ Touch Screen Color Display
  • Optional Integrated Biometrics
  • Closed Loop Architecture of Notes and Coins
  • Additional Deposit Capacity in the 4S XL Model
  • Coin Discrimination (i.e. Counterfeit Coin Rejection)
  • Recycle and Lockable Deposit Cassettes
  • “Fitness Sort” on Recycled Notes
  • Flexible Note Orientation (No Need to Separate or Face Notes)
  • Integrated Drop/Storage Vault in the 4S Model
  • Optional Integrated Printer
  • Scalable Platform
  • Network and Cluster Multiple Devices
  • Continuous 24/7 Monitoring
  • Vault – UL 291 Business “Hours Rated”
  • UPS Included

Quantum 4S XL with Auxiliary Vault

SPECIFICATIONS

Height: 30.8” (781 mm)

Width: 46.5” (1181 mm))

Depth: 24.1” (611 mm) install depth
Depth: 24.0” (610 mm) servicing depth
Depth: 27.8” (707 mm) transit/transportation clearance

Weight: 715 lbs. (324 kg) empty

HARDWARE FEATURES
  • 10″ Touch Screen Color Display
  • Optional Integrated Biometrics
  • Closed Loop Architecture of Notes and Coins
  • Additional Deposit Capacity in the 4S XL Model
  • Coin Discrimination (i.e. Counterfeit Coin Rejection)
  • Recycle and Lockable Deposit Cassettes
  • “Fitness Sort” on Recycled Notes
  • Flexible Note Orientation (No Need to Separate or Face Notes)
  • Integrated Drop/Storage Vault in the 4S Model
  • Optional Integrated Printer
  • Scalable Platform
  • Network and Cluster Multiple Devices
  • Continuous 24/7 Monitoring
  • Vault – UL 291 Business “Hours Rated”
  • UPS Included
  • Auxiliary Vault – 2.64 Cubic Feet Internal Space; Each Unit Comes with 2 Adjustable Shelves
